(47) for a regular Schrodinger electron or
(48) for graphene, with Fermi velocity υ F , which implies two important limitations of any WKB approximation: a sharp, sudden change of the potential V ( x ) and the regions in the vicinity of the turning points, where p ( x ) → 0 . At the same time, all the results for Klein tunneling over a square barrier with sharp edges and V ( x ) = V 0 Θ ( x ) Θ ( W B − x ) , where W B is constant, are faithfully reproduced by WKB theory, which appears to be valid much beyond its known range of applicability. At the time, WKB methods provide a straightforward and reliable estimate of the electron transmission amplitudes for the cases when traditional techniques are impossible or extremely complicated, such as for our case of Kek-Y-patterned graphene. The validity of the WKB method is determined not by the size or height of the potential barrier. However, we should require the potential profile to be smooth and apply the approximation far from the turning points where the momentum of our particle becomes equal or close to zero. 5. Concluding RemarksIn conclusion, we have built a complete semi-classical WKB theory for recently discovered Kek-Y-patterned graphene with two coupled gapless Dirac cones with different Fermi velocities v F ( 1 ± Δ 0 ) . This includes finding the semi-classical action, x-dependent longitudinal momentum p x ( x ) and leading-order WKB wave function. Meanwhile, we have also derived and solved the transport equation, which connects every two successive orders of a sought wave function. Our obtained WKB equations are further applied to calculate the electron transmission amplitudes based on classically inaccessible regions. We have demonstrated that the slope a of a linear potential V ( x ) = a x can strongly affect electron transmission, while the coupling parameter Δ 0 has a very limited effect on transmission, because it only slightly modifies the location and size of a classically forbidden region for a specified incoming electron. Our obtained results have numerous applications to constructing and operating a new generation of electronic devices, since the electron transmission amplitude is directly related to the quantum transport in our material. Most of the known models for the electron conductivity, such as Kubo formalism, require the exact knowledge of electron transmission. Applied irradiation could induce or modify the existing bandgap and greatly affect the electron transmission, which is crucial for optoelectronic applications. We are strongly convinced that this work reveals a crucial step in advancing our knowledge on the electronic properties of newly discovered Dirac materials. Our obtained WKB theory provides a powerful tool for systematically investigating crucial electronic and transport properties of novel Dirac materials, which have numerous applications in modern electronic and opto-electronic devices, and especially in valleytronics. Author ContributionsMethodology, A.I., G.G. and L.Z.; Supervision, A.I. and G.G.; Writing—original draft, A.I., L.Z., G.G. and D.H.; Writing—review & editing, G.G. and D.H. All authors have read and agreed to the published version of the manuscript. FundingA.I. would like to acknowledge the funding received from TRADA-53-130 PSC-CUNY Award 65094-00 53. D.H. was supported by the Air Force Office of Scientific Research (AFOSR). G.G. would like to acknowledge Grant No. FA9453-21-1-0046 from the Air Force Research Laboratory (AFRL). Institutional Review Board StatementNot applicable. Informed Consent StatementNot applicable. Conflicts of InterestThe authors declare no conflict of interest. References
Figure 1. Atomic structure of Kekulé-distorted graphene: honeycomb lattices of graphene with additional Kek-Y bond texture due to the presence of a substrate. Figure 1. Atomic structure of Kekulé-distorted graphene: honeycomb lattices of graphene with additional Kek-Y bond texture due to the presence of a substrate.  Figure 2. (a,b) Energy dispersions ε Y ( s 1 , s 2 | k , Δ 0 ) for Kek-Y graphene represented by two nonequivalent Dirac cones with different Fermi velocities v F , 1 and v F , 2 corresponding to v F ( 1 ± Δ 0 ) . Here, s 1 = ± 1 is a band index, while s 2 = ± 1 corresponds to two different Fermi velocities due to strain coupling Δ 0 . Figure 2. (a,b) Energy dispersions ε Y ( s 1 , s 2 | k , Δ 0 ) for Kek-Y graphene represented by two nonequivalent Dirac cones with different Fermi velocities v F , 1 and v F , 2 corresponding to v F ( 1 ± Δ 0 ) . Here, s 1 = ± 1 is a band index, while s 2 = ± 1 corresponds to two different Fermi velocities due to strain coupling Δ 0 . Figure 3. Regions for the classically forbidden (or classically inaccessible regions) with Im p x ( x ) ≠ 0 for an incoming electron with a linear potential V ( x ) = a x . Here, we select a crossing point, corresponding to the electron-to-hole (and back) state transition ε Y ( s 1 , s 2 | k , Δ 0 ) = 0 at x = 0 . All panels (a–d) are calculated for Δ 0 = 0 but different values of a. Figure 3. Regions for the classically forbidden (or classically inaccessible regions) with Im p x ( x ) ≠ 0 for an incoming electron with a linear potential V ( x ) = a x . Here, we select a crossing point, corresponding to the electron-to-hole (and back) state transition ε Y ( s 1 , s 2 | k , Δ 0 ) = 0 at x = 0 . All panels (a–d) are calculated for Δ 0 = 0 but different values of a. Figure 4. Regions for the classically forbidden (or classically inaccessible regions) with Im p x ( x ) ≠ 0 for an incoming electron with a linear potential V ( x ) = a x . Here, we select a crossing point, corresponding to the electron-to-hole (and back) state transition ε Y ( s 1 , s 2 | k , Δ 0 ) = 0 at x = 0 . Panels (a–d) are calculated with a = 1 and various finite values of Δ 0 . Figure 4. Regions for the classically forbidden (or classically inaccessible regions) with Im p x ( x ) ≠ 0 for an incoming electron with a linear potential V ( x ) = a x . Here, we select a crossing point, corresponding to the electron-to-hole (and back) state transition ε Y ( s 1 , s 2 | k , Δ 0 ) = 0 at x = 0 . Panels (a–d) are calculated with a = 1 and various finite values of Δ 0 . Figure 5. Transmissions amplitudes T p y | a , Δ 0 calculated by using Equation (). Panel (a) presents T p y | a , Δ 0 as a function of transverse momentum p y for Δ 0 = 0 and different slopes a = 0.2 and 0.5 . Panel (b) displays calculated T p y | a , Δ 0 as a function of p y for a = 0.2 and different energy gaps Δ 0 = 0 and 0.5 . Figure 5. Transmissions amplitudes T p y | a , Δ 0 calculated by using Equation (). Panel (a) presents T p y | a , Δ 0 as a function of transverse momentum p y for Δ 0 = 0 and different slopes a = 0.2 and 0.5 . Panel (b) displays calculated T p y | a , Δ 0 as a function of p y for a = 0.2 and different energy gaps Δ 0 = 0 and 0.5 . Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content. © 2023 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access article distributed under the terms and conditions of the Creative Commons Attribution (CC BY) license (https://creativecommons.org/licenses/by/4.0/). Share and CiteMDPI and ACS Style Iurov, A.; Zhemchuzhna, L.; Gumbs, G.; Huang, D. Application of the WKB Theory to Investigate Electron Tunneling in Kek-Y Graphene. Appl. Sci. 2023, 13, 6095. https://doi.org/10.3390/app13106095 AMA Style Iurov A, Zhemchuzhna L, Gumbs G, Huang D. Application of the WKB Theory to Investigate Electron Tunneling in Kek-Y Graphene. Applied Sciences. 2023; 13(10):6095. https://doi.org/10.3390/app13106095 Chicago/Turabian Style Iurov, Andrii, Liubov Zhemchuzhna, Godfrey Gumbs, and Danhong Huang. 2023. "Application of the WKB Theory to Investigate Electron Tunneling in Kek-Y Graphene" Applied Sciences 13, no. 10: 6095. https://doi.org/10.3390/app13106095 Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here. Is Physical Review a good journal?The world's premier physics letter journal, PRL is the most-cited journal in physics and 8th most-cited in all of science. PRL is the highest-impact letters journal in the Physics, Multidisciplinary category. What is the impact factor of the journal of Physical Review B?About Physical Review B We have an impact factor of 3.322 (2008) and are ranked number one in total citations in condensed matter physics. The editors of PRB are primarily full-time staff at the Ridge, New York office on Long Island, who are dedicated to managing a fair and thorough review process. Is Physical Review applied open access?All Physical Review journals share many common policies, covering professional conduct, publication rights, copyright, research involving animal and human subjects, and open access. What is the abbreviation for physical review letters?Physical Review Letters (PRL), established in 1958, is a peer-reviewed, scientific journal that is published 52 times per year by the American Physical Society. |
